該產品系列在原有接點結構1NC/1NO和2NC的基礎上，新 增了配備2NC/1NO及3NC接點結構的3接點型和MBB型。
M12連接器型，更加節省勞動力，更換更方便。
標準化的鍍金接點保證了接觸的高可靠性。 適用于標準負載和微小負載。
多種金屬頭部可選。
訂購未在該表中列出的型號時，請與歐姆龍代表處聯系。
強制斷開的認定型號
| 類型 | 接點結構 | 導管口/連接器 | 型號 | |
|---|---|---|---|---|
| 1導管 | 慢動型 | 1NC/1NO | Pg13.5 | D4NS-1AF * |
| G1/2 | D4NS-2AF * | |||
| M20 | D4NS-4AF | |||
| 2NC | Pg13.5 | D4NS-1BF * | ||
| G1/2 | D4NS-2BF * | |||
| M20 | D4NS-4BF | |||
| 2NC/1NO | Pg13.5 | D4NS-1CF * | ||
| G1/2 | D4NS-2CF * | |||
| M20 | D4NS-4CF | |||
| 3NC | Pg13.5 | D4NS-1DF * | ||
| G1/2 | D4NS-2DF * | |||
| M20 | D4NS-4DF | |||
| 慢動型MBB接點 | 1NC/1NO | Pg13.5 | D4NS-1EF | |
| G1/2 | D4NS-2EF | |||
| M20 | D4NS-4EF | |||
| 2NC/1NO | Pg13.5 | D4NS-1FF | ||
| G1/2 | D4NS-2FF | |||
| M20 | D4NS-4FF | |||
| 2導管 | 慢動型 | 1NC/1NO | G1/2 | D4NS-6AF |
| M20 | D4NS-8AF | |||
| 2NC | G1/2 | D4NS-6BF | ||
| M20 | D4NS-8BF | |||
| 2NC/1NO | G1/2 | D4NS-6CF | ||
| M20 | D4NS-8CF | |||
| 3NC | G1/2 | D4NS-6DF | ||
| M20 | D4NS-8DF | |||
| 慢動型MBB接點 | 1NC/1NO | G1/2 | D4NS-6EF | |
| M20 | D4NS-8EF | |||
| 2NC/1NO | G1/2 | D4NS-6FF | ||
| M20 | D4NS-8FF | |||
| 1導管 (帶連接器) |
慢動型 | 1NC/1NO | M12連接器 | D4NS-9AF |
| 2NC | D4NS-9BF | |||
| 慢動型MBB接點 | 1NC/1NO | D4NS-9EF | ||
| 1導管 (強拉力型) |
慢動型 | 1NC/1NO | G1/2 | D4NS-2AF-SJ * |
| M20 | D4NS-4AF-SJ * | |||
| 2NC | G1/2 | D4NS-2BF-SJ * | ||
| M20 | D4NS-4BF-SJ * | |||
| 2NC/1NO | G1/2 | D4NS-2CF-SJ * | ||
| M20 | D4NS-4CF-SJ * | |||
| 3NC | G1/2 | D4NS-2DF-SJ * | ||
| M20 | D4NS-4DF-SJ * | |||
*已通過韓國S-mark認證的型號。
